Motor Type only
        Permanent life type using Solid Tire(Urethane Tire) for rear wheel
        Available for successive drive up to 60km per charge
        Uses BL DC motor suitable for long distance operation
          (Durability is permanent)
        Available for inputting various programs by digital control and
          adapted update drive way which doesn't need any decelerator
          or speed change
        Excellence in speed ability and mount capability

















Drive way



Direct drive of rear wheel

Remarks

Motor

Type

BRUSHLESS DC



Regular output

200W ¡¿ 2EA



Regular voltage

DC 24V



Battery



12V 40AH ¡¿ 2EA

For charge

Function

Drive speed

2.0Km/h~6.5Km/h

4Phse speed Change Gear Drive

Drive Distance

60Km

When charged fully(100%)

Mount capability

15¡Æ

weight 60Kg

Rear Wheel



14¡Æ(350m/m)

Fixed Type

Front Wheel



7¡Æ(180m/m)

Air~Tube
