Available as Motor type with manual operation

Easy handling with detachable rear wheel
        Available for driving up to 40km per charge

Uses BL DC motor suitable for long distance operation
        Available for inputting various programs by digital control and
          adapted update drive way which doesn't need any decelerator
          for speed change
        Quiet motor
        No strength decline for a long term operation
        Excellence in speed ability and mount capability

















Drive way



Direct drive of rear wheel

Remarks

Motor

Type

BRUSHLESS DC



Regular output

200W ¡¿ 2EA



Regular voltage

DC 24V



Battery



12V 40AH ¡¿ 2EA



Function

Drive speed

2.0Km/h~6.5Km/h

4Phse speed Change Gear Drive

Drive Distance

80Km

When charged fully(100%)

Mount capability

15¡Æ

weight 50Kg

Rear Wheel



14¡Æ(350m/m)

Fixed Type

Front Wheel



7¡Æ(180m/m)

Air~Tube
